40′ Lightweight Gooseneck 5-axle chassis

$16,000.00

Introducing the 40′ Lightweight Gooseneck 5-Axle Chassis—your ideal solution for heavy load transportation. Engineered for strength and fuel efficiency, this durable chassis ensures a smooth ride on any terrain. Elevate your hauling capabilities with this versatile and reliable gooseneck chassis!

Compare
Add to wishlist
Category:
Description

40′ Lightweight Gooseneck 5-axle chassis General Specs

Tare Weight:
8,900
GVWR:
75,000 lb.
Main Beams:
Fabricated
Upper Coupler Assembly:
Pick up plate is 5/16 inch thick
Fifth Wheel Height:
47 1/2 in.

Dimensions

Overall Chassis Width:
96 in.
Maximum Rear Height:
48 in.
Overall Chassis Length:
40 ft. 6 in.

Landing Gear

Landing Gear:
50,000 lift, 160,000 static load capacity
Landing Gear Foot Group:
10 x 10 low profile sand shoes

Lighting

Light Attachment:
Flange mounted
Light Type:
LED

Brakes

Drum:
Centrifuse
Lubrication:
Synthetic grease
Brake System Type:
4S/2M
Brake Chambers:
30/30

Wheels

Rims:
8.25 X 22.5 standard polish aluminum
Tires:
295/75R 22.5

Axles

Axle Type:
5.75″ round, 71.5″ long, parallel spindle
Axle Quantity:
4 fixed plus 1 lift/steer

Suspension

Suspension Type:
4 spring-ride plus 1 air-ride lift/steer
Springs:
one-leaf

Finish

Primer:
Zinc-rich
Topcoat:
Black urethane
